Profile：— 6 placement heads — Servo motor drives X and Y axes — Z-axis mobile drive system — High precision fixed vision system / flight alignment identification system — Visible range: □32×32mm (0.3mm pitch), connector — Flight alignment system: 1005 (Inch 0402) ~ QFP□ 22×22mm ?? (0603 inch 0201)~QFP□12×12mm (optional) — Maximum component placement height: 12mm standard — 2D foot bending check — Placement rate: (under optimal placement conditions) ?? Chip: 0.178sec/piece ?? QFP: 0.75sec/piece (flight alignment) ?? QFP: 1.6sec/piece (fixed vision system) The substrate range is 50×30~460×400 T=0.38~4.2mm ?? Can load 98 (8mm) belt feeders (104 optional) — Safety cover interlock function — Windows 98 software operation — Power supply: single phase 100~240V 50/60HZ — gas source: 5 bar, no water, no oil or dust — Air consumption: 150NL/min
